DC24-48V 800W Brushless DC Motor Driver Controller OK3BL30ZR 30A Support RS-485 Communication

This brushless DC driver features stable performance with a DSP-based computing core and multiple control modes. The fully digital design allows for flexible input control methods and comprehensive software and hardware protection functions. The driver can be connected to a computer via the RS-485 communication interface for parameter adjustment, including settings for protection parameters, motor parameters, and acceleration and deceleration times.

Speed ​​regulation mode:

1: 0-5VDC analog input;
2: 0-100% PWM input (PWM frequency range: [1Kz-2OKHz);
3: External potentiometer speed control;
4: Setting via RS-485 communication.

Electrical Specifications:

Electrical Parameters(Tj=25ºC);
Related Voltage:24-48V
Related Current:30A
Input voltage:14~60VDC, (Typical 24V);
Current output:3A-30A; (Typical 30A);
Applicable motor speed:100-30000rpm (Typical 3000rpm)
Over-voltage and over-current protections;
CE certified and RoHS compliant;

Operating Environment and other Specifications(Tj = 25℃/77℉):

Cooling: Natural Cooling or Forced cooling
Environment: Avoid dust, oil fog and corrosive gases
Ambient Temperature: 0℃ － 65℃
Humidity: 40%RH－90%RH
Operating Temperature: 0℃ － 50℃
Vibration: 10-55Hz / 0.15mm
Storage Temperature: -20℃ － 65℃
Demension:151*97.5*52.6mm
Weight: Approx.160g;
